Hi Folks,Yesterday I have read about XPI Inspector and have used it for the first time. I have found this very interesting. Although many of you may be aware of it but also I feel there are many people who may not be aware of this. So I thought I would share few points I learnt.To start with, XPI Inspector is basically a tool developed by SAP which is a web application for collecting information about XI-related configurations and traces.The tool also performs certain number of configuration checks, such as SSL client/server verification.Which checks are executed depends on the selected example or the type and properties of the selected XI communication channelsThe tool does not do any configuration changes on the system. All collected information is saved on the file system of the central Java instance and is available for review.Note that in order to perform some checks, such as verification of SSL client connections, the tool automatically opens a dummy https or ftps connection to the remote ssl serverSeveral additional general options are available for selection:1.

• Sap Xpi Inspector

Collect debug traces from Messaging System2. Collect debug trace from XI Module Processor3. Collect HTTP Traces4. Collect Open SQL Traces5. Collect JCo Traces6.

Collect information about the system state.Download the file named “xpiinspectorear.ear” from the sap marketplace.Deploy the tool on the XI Adapter Engine which you would like to inspect. Note that if you download the file from the web version that the extension of the file could be changed from EAR to ZIP. In this case you have to rename it again right after download from ZIP to EAR.To deploy on 6.40 or 7.00 server version use SDM.To deploy on 7.10 or above server versions use one of the following options:. Deploy View Plug-in from SAP NWDS. Telnet command: deploy versionrule=all. JSPM toolOpen a new browser window and load the “XPI Inspector” by using the following url address: http(s)://:/xpiinspectorThe recommended browser is Microsoft IE.You will need administrator’s credentials to access the XPI Inspector.Select the example to use.

Sap Xpi Inspector

SAP shall inform you in advance which example you need.Follow all the instructions displayed on the screen.Basically, you need to perform the following three steps:1. Select the example and start the inspection.2. Reproduce the problem and stop the inspection right after the problem occurs.3.
